Description
Havis Mounting and Docking Equipment
A Panasonic Toughbook or Toughpad can be complemented and turned into a mobile work space with the proper mounting and docking equipment. The Rugged Store is pleased to be partnered with some of the best mounting and docking manufacturers in the business. One of the best known manufacturers and producers of high quality products is Havis. Havis has been creating mounting and docking for Panasonic Toughbooks and Toughpads for many years. The Rugged Store has access to the complete Havis catalog of equipment, if you can’t find the right part to building your Havis equipment solution, be sure to contact us so we can help you find it.
Havis Dock for the Panasonic Toughbook CF-31
Toughbook certified by Panasonic, this Havis dock was built to be compatible with Non Pass-Through models of the CF-30 and CF-31 Panasonic Toughbook. Constructed out of aircraft grade aluminum and impact resistant plastic, a Havis dock compliments the rugged nature of a Panasonic Toughbook and adds a layer of mobility to the rugged notebook. Offering full port replication the DS-PAN-112 includes power supply.
Havis Dock DS-PAN-112 Product Details:
- Toughbook Certified docking station for Panasonic Toughbook CF-30 and CF-31 laptops with power supply
- Includes Lind power supply with customized cord length and connector tip strain relieved to prevent damage and accidental disconnects
- Low profile design maximizes available space inside of vehicle
- Full port replication and integrated strain relieving provide simple, safe, and secure connectivity to essential peripherals, as well as convenient and efficient cable management
- Rounded corners and edges are ideal for your safety in accidents and airbag deployment, in addition to daily use and operation of docking station
- Designed to fit all Havis mounting equipment and most competitors mounting equipment
- Lock and key supplied for peace of mind theft deterrence
Havis Dock DS-PAN-112 Specifications:
- Compatible computer: Panasonic Toughbook CF-30 and CF-31
- Dimensions: 12.4″ (31.5 cm) x 11.8″ (29.9 cm) x 3.8″ (9.7 cm)
- Certifications: Vibration Testing: MIL-STD 810G 514.5, Panasonic: Toughbook Certified, crash test: SAE J1455 30mph Crash Testing, cycle test: latch handle & docking connectors mechanism 30,000 cycles
- Connectivity includes: serial: DB9 (9-Pin) connection (2), VGA: (1), speaker: stereo (1), microphone: stereo (1), USB: fully-powered USB 2.0 (5), Ethernet: RJ45 Ethernet (2), noise filtering: yes, input voltage: 15.6V dc
- Weight: 5.8 lbs. (2.2 kg)
- Gross Weight: 7.80 lbs
