Description
Havis Mounting and Docking Equipment
A Panasonic Toughbook or Toughpad can be complemented and turned into a mobile work space with the proper mounting and docking equipment. The Rugged Store is pleased to be partnered with some of the best mounting and docking manufacturers in the business. One of the best known manufacturers and producers of high quality products is Havis. Havis has been creating mounting and docking for Panasonic Toughbooks and Toughpads for many years. The Rugged Store has access to the complete Havis catalog of equipment, if you can’t find the right part to building your Havis equipment solution, be sure to contact us so we can help you find it.
Havis Dock for the Panasonic Toughbook CF-19
Toughbook certified by Panasonic, this Havis dock was built to be compatible with Dual Pass-Through models of the CF-19 Panasonic Toughbook. Constructed out of aircraft grade aluminum and impact resistant plastic, a Havis dock compliments the rugged nature of a Panasonic Toughbook and adds a layer of mobility to the rugged notebook. The DS-PAN-211-2 Havis dock is built specifically for Panasonic Toughbook CF-19 models which are mk4 or higher.
Havis Dock DS-PAN-211-2 Product Details:
- Part number DS-CF19-HGD discontinued, we will not accept any more parts orders for the old part numbers, please use new part number DS-PAN-211-2
- Docking station: Panasonic Toughbook tested with dual hi-gain antenna
- Panasonic CF19 (mark 4 and higher) Toughbook compatible docking station
- Connectivity includes: serial: DB9 (9-Pin) connection (2), VGA: (1), speaker: stereo (1), microphone: stereo (1), USB: fully-powered USB 2.0 (4), Ethernet: RJ45 Ethernet (1), antenna: dual hi-gain (tnc connectors), noise filtering: yes, emi filtering: yes
- Construction: aircraft grade aluminum uni-body with glass reinforced pc-abs impact resistance plastic covers
- Certifications: Vibration Testing: MIL-STD 810G 514.5, Panasonic: Toughbook Certified
- Height 1: 3.3 in (8.2 cm), height 2: 11.0 in (27.9 cm), width 1: 10.9 in (27.7 cm)
- Product weight: 4.0 lbs.
- Power supply & cable LPS-101 sold separately
- Screen stiffener DS-DA-405 sold separately
Havis Dock DS-PAN-211-2 Specifications:
- Dimensions: 11.0″ (27.9 cm) x 10.9″ (27.7 cm) x 3.3″ (8.2 cm)
- Certifications: Vibration Testing: MIL-STD 810G 514.5, Panasonic: Toughbook Certified, crash test: SAE J1455 30mph Crash Testing, cycle test: latch handle & docking connectors mechanism 30,000 cycles
- Connectivity includes: serial: DB9 (9-Pin) connection (2), VGA: (1), speaker: stereo (1), microphone: stereo (1), USB: fully-powered USB 2.0 (4), Ethernet: RJ45 Ethernet (1), noise filtering: yes, emi filtering: yes, input voltage: 15.6V dc
- Weight: 5.3 lbs. (2.4 kg)
- Gross Weight: 5.90 lbs
