Description

Havis Mounting and Docking Equipment

A Panasonic Toughbook or Toughpad can be complemented and turned into a mobile work space with the proper mounting and docking equipment. The Rugged Store is pleased to be partnered with some of the best mounting and docking manufacturers in the business.  One of the best known manufacturers and producers of high quality products is Havis.  Havis has been creating mounting and docking for Panasonic Toughbooks and Toughpads for many years.  The Rugged Store has access to the complete Havis catalog of equipment, if you can’t find the right part to building your Havis equipment solution, be sure to contact us so we can help you find it.

Havis Vehicle Specific Console for 2021 Ford F-150 Wide-Angled 30″ Long C-VS-3000-F150-2

Product Details:

• 30″ long 12.5″ wide vehicle specific console for 2021 Ford F-150 police responder, Special Service vehicle (SSV)
• Also fits retail versions with column shifter (with 40-20-40 split front seat, without OEM console)
• Angled console cleanly fits between the bucket seats and the dash contour for a custom look in your vehicle
• Heavy gauge steel, welded construction for Heavy-duty use and durability
• Black powder coat finish
• Lifetime warranty
• Made in the USA

• Includes:

• Two 12V DC “lighter plug” outlets with attached caps
• Two rectangle rocker switch cutouts with blank covers
• Filler plates (FP) and/or equipment brackets (EB) to completely enclose mounting area less internal mount options
• Large accessory pocket (13″ long x 2.5″ wide x 8″ deep) and internal front electrical equipment mounting shelf
• Provisions for internal or external side mount poles and side panels with perforations to allow for equipment cooling as well as internal speaker mounting
• Vehicle mounting kit, no drilling required

Specifications:

• Overall measurements = 12.89″ high x 9″ wide x 38″ long (including forward trim panel)
• See side view drawing for min/max mounting depth allowed for control heads and/or options
• OEM tunnel plate must be removed
• If using console with a vertical gun rack between seats, a partition with gun alcove is recommended. there is 9.5″ from end of console to Pro-gard a partition gun alcove. dual weapons mount not recommended because of lack of space
• Does not work on higher trim levels with OEM full length center console that includes mounted shifter (OEM console cannot be removed)
• Does not work with 4 x 4 floor shifter (works with dash mounted 4 x 4 selector switch)
• Gross Weight: 52.00 lbs
